#58624 03/31/2006 4:32 PM | Joined: Mar 2006 Posts: 21 'Bolter | | 'Bolter Joined: Mar 2006 Posts: 21 | Hi everybody, my name is Bill and I'm a gearaholic.
54 yrs old and in my 5th childhood.I've got a 53 half ton truck project but my question concerns a roadster pickup i'm building out of my scrap pile.
I have an extra 216 with a top loader 4spd I want to use but I need it to work with an open driveshaft. Is this doable or should I hunt up another tranny ?
I'd really like to keep a top loader though.
Thanks. I'm going back to the archives now :-) | | |
#58625 03/31/2006 5:16 PM | Joined: Jan 2004 Posts: 223 'Bolter | | 'Bolter Joined: Jan 2004 Posts: 223 | LilBill, assuming this is a SM420 GM 4sp, this is no problem. From '55 through '67 GM used the same tranny with an open driveline. All you need to find is the rear coverplate and rear yoke from one of these transmissions. Swap out the rear yoke and coverplate on the earlier tranny and you are done.
Steve O | | |
#58626 03/31/2006 7:36 PM | Joined: Jul 2005 Posts: 1,158 Shop Shark | | Shop Shark Joined: Jul 2005 Posts: 1,158 | If it's a 216, chances are the tranny's a Coffee Grinder/Rock Crusher 4 speed.
What're the Engine and Tranny Serial Numbers? that should tell us what the original application was. My 4 speed is original equipment for my 3/4 ton (as far as I can tell) and it has an open driveline.
Half ton and Car Trannies had the Torque Tube setup that I don't think will work for an open driveline.
Wish I could help you more. Let us know what the numbers are, and we can probably let you know one way or another. | | |
#58627 03/31/2006 7:51 PM | Joined: Nov 2000 Posts: 1,966 'Bolter | | 'Bolter Joined: Nov 2000 Posts: 1,966 | Welcome to the Stovebolt Page. Glad to have you. Tell us more about your project. Is the 4-speed a truck trans like we are guessing? Does it have the little lever/rod to put it in reverse? If so then it's a non-synchro pre-48. What's it out of? Nifty50 is right, if it's a SM420 and has a torque tube ball/socket on the end then it's from a 1/2 ton or 3/4 ton. Bigger trucks at least from 48 had an open yoke. Good luck.
Professional Novice
| | |
#58628 03/31/2006 8:41 PM | Joined: Oct 2005 Posts: 4,252 "Hey! I sound like Darth Vader!! | | "Hey! I sound like Darth Vader!! Joined: Oct 2005 Posts: 4,252 | | | |
|
|
| |
